64 OPERATION
Closing case
Pull release lever 2 all the way up.
Close case lid and press down. Make sure
that no objects are jammed.
The case can also be locked if the lock
is in the LOCK position. Under such
circumstances, ensure that the ignition key is
not in the case.
Press release lever 2 down until it en-
gages.
Turn vehicle key to the LOCK position in
the case lock and remove it.
Maximum payload and maximum speed
Observe maximum payload and maximum
speed.
The following values apply to the combina-
tion described here:
Maximum speed when riding with a
loaded case
max 99 mph (max 160 km/h)
Payload per case
max 22 lbs (max 10 kg)
SEAT
Removing the seat
Park the vehicle, making sure that the
ground is firm and level.
Remove screw 3 with tool from onboard
vehicle tool kit.
Remove holder 4.
Remove the seat 1 in the arrow direction
and, carefully pull out the grab strap 2 at
the same time.
with seat heating
OE
Park the vehicle, making sure that the
ground is firm and level.
Remove screw 3 with tool from onboard
vehicle tool kit.
Remove holder 4.
Lift the seat 1 in the arrow direction and
carefully pull out the grab strap 2 at the
same time.
