65
Disconnect the plug connection 2 and re-
move the seat 1.
Installing the seat
Thread the grab strap 2 into the seat 1.
Insert the seat 1 into the mount 5.
Position the seat 1 in the rear area and
install the holder 4 using the screw 3.
with seat heating
OE
Position the seat 1 and connect the plug
connection 2.
Thread the grab strap 2 into the seat 1.
Insert the seat 1 into the mount 5.
Position the seat 1 in the rear area and
install the holder 4 using the screw 3.
