BNF BLADE 450 X - Transmitter Setup: DX6 i and DX7;DX7 se; Spektrum DX6 i Configuration; Spektrum DX7;DX7 se Configuration

5
EN
Transmitter Setup
Spektrum DX6i
SETUP LIST
SYSTEM LIST
ADJUST LIST
ADJUST LIST
POS-0POS-0 POS-1
Spektrum DX7/DX7se
Model Type Reverse Swash Type Timer
HELI THRO—N 1Servo90Degree Type—Down
AILE—N Time—4:00
ELEV—N
Switch—
Trainer
RUDD—R
GYRO—N
PITC—R
Model Type Swash Type Input Select
HELI
1ServoNorm
AUX2 GEAR
INH GYRO
D/R Expo
AILE 0 100% INH
ELEV0 100% INH
RUDD0 100% INH
AILE 1 85% INH
ELEV1 85% INH
RUDD1 85% INH
AUTO D/R EXP
NORM INH
ST-1 INH
ST-2 INH
HOLD INH
AILE ELEV RUDD
EXP LIN EXP LIN EXP LIN
D/R100% D/R100% D/R100%
AILE ELEV RUDD
EXP LIN EXP LIN EXP LIN
D/R85% D/R85% D/R85%
TRAVEL ADJUST
THRO 100%
AILE 100%
ELEV 100%
RUDD 100%
GYRO 100%
PITC 100%
TRAVEL ADJUST
THRO AILE
H 100% L 100%
L 100% R 100%
ELEV RUDD
D 100% L 100%
U100% R 100%
GEAR PIT
+ 100% H 100%
-100% L 100%
AUX2
+ 100%
-100%
SUB-TRIM*
THRO 0
AILE 0*
ELEV 0*
RUDD 0*
GYRO 0
PITC 0
SUB-TRIM*
THRO 0
AILE 0*
ELEV 0*
RUDD 0*
GEAR 0
PITC 0
AUX2 0
GYRO
Rate SW-F.Mode
0 77.0% NORM 0
1 77.0% STUNT 0
GYRO SENS
AUTO F.MODE
RATE NORM 0
0 77.0% STNT 0
1 77.0% HOLD 0
THRO HOLD
HOLDPOS 0.0%
SW RUDDD/R
TIMER
DOWN-T 4:00
SWASH MIX
INH
REVERSING SW
THRO AILE ELEV RUDD GEAR PIT AUX2
N N N R N N N
THRO CUR
L 2 3 4 H
NORM 0% 30% 60% 60% 60%
STUNT 100% 100% 100% 100% 100%
HOLD 10% 10% 10% 10% 10%
THRO CURVE
L 1 2 3 H
NORM 0% 30% 60% 60% 60%
ST-1 100% 100% 100% 100% 100%
ST-2 100% 100% 100% 100% 100%
PITC CUR
L 2 3 4 H
NORM 30% 40% 50% 75% 100%
STUNT 0% 25% 50% 75% 100%
HOLD 0% 25% 50% 75% 100%
PITCH CURVE
L 1 2 3 H
NORM 30% 40% 50% 75% 100%
ST-1 0% 25% 50% 75% 100%
ST-2 0% 25% 50% 75% 100%
HOLD 0% 25% 50% 75% 100%
SWASH MIX
INHIBIT
Program your transmitter before attempting to bind or fly the helicopter. TransmitterprogrammingvaluesareshownbelowfortheSpektrumDX6i,DX7/
DX7se,DX7sandDX8.TheSpektrummodellesforAirWare™transmittersarealsoavailablefordownloadonlineintheSpektrumCommunity.
NOTICE:WhenusingaFutabatransmitterwithaSpektrumDSMmodule,youmustreversethethrottlechannel.
*Neverusesub-trimsortrimsonAILE,ELEVorRUDDchannelswiththeAR7200BX.
*Neverusesub-trimsortrimsonAILE,ELEVorRUDDchannelswiththeAR7200BX.
