Installing the Flight Battery
CAUTION: AlwaysdisconnecttheLi-Pobatteryfromtheaircraftreceiverwhennotyingtoavoidover-dischargingthebattery.Batteriesdischargedtoa
voltage lower than the lowest approved voltage may become damaged, resulting in loss of performance and potential fire when batteries are charged.
WARNING: YoumustmovethethrottletotheLOW/OFFpositionduringbinding.Failuretodosomaycausetherotorbladestospinandthe
helicopter to lift during the AR7200BX initialization, which could result in damage to property and injury.
1. Lower the throttle.
2. Power on the transmitter.
3.Centerthethrottletrim.
4.ToallowtheESCtoarmandtokeeprotorsfrominitiatingatstartup,turn
onthrottleholdandnormalightmodebeforeconnectingtheight
battery. Please refer to your transmitter manual for more information on
programmingthrottleholdandnormalightmode.
5.Attachhookmaterialtothehelicopterframeandloopmaterialtothe
battery.
6.Installtheightbatteryonthehelicopterframe.Securetheightbattery
withahookandloopstrap.ConnectthebatterycabletotheESC.
CAUTION:AlwayskeepthepowerleadpositionedAWAYfromtheeleva-
tor servo. Failure to do so could cause the lead to get caught, resulting
in a crash causing property damage and injury.
CAUTION: Makesuretheightbatterydoesnotcomeincontactwith
themotor.Failuretodosowillcausethemotor,ESCandbatteryto
overheat, resulting in a crash causing property damage and injury.
7. Do not move the helicopter until the AR7200BX initializes. The swashplate
will move up and down, indicating that the unit is ready. The AR7200BX
willalsoemitasolidBLUEStatusLEDwhenitisready
8.Thehelicoptermotorwillemit2tones,incdicatingtheESCisarmed.
Binding Procedure
1. ProgramyourtransmitterusingtheTransmitterSetupfoundinthismanual.
2. InsertthebindplugintheBND/DATportonthereceiver.
3. ConnecttheightbatterytotheESC.TheHmenuLEDshouldbeashing,indicatingtheAR7200BXisinbindmode.
4. Movethethrottlesticktothedesiredfailsafeposition(lowthrottlepositioninnormalmode).
5. FollowtheproceduresofyourspecictransmittertoenterBindMode.Thesystemwillconnectwithinafewseconds.Onceconnected,theHLEDwill
turn off and the AR7200BX will start the initialization process.
6. Whentheinitializationprocessiscomplete,menuLEDHwillturnOFFandtheStatusLEDlightwillcomeONsolidBLUE.
7. DisconnecttheightbatteryandremovethebindplugfromtheAR7200BX.Storethebindpluginaconvenientplace.
NOTICE: Removethebindplugtopreventthesystemfromenteringbindmodethenexttimethepoweristurnedon.
If you encounter problems, obey binding instructions and refer to transmitter troubleshooting guide for other instructions. If needed, contact the appropriate
HorizonProductSupportofce.
ForalistofcompatibleDSM®transmitters,pleasevisitwww.bindny.com.
BindingistheprocessofprogrammingthereceivertorecognizetheGUID(GloballyUniqueIdentier)codeofasinglespecictransmitter.Youneedto‘bind’your
chosenSpektrum™DSM2™/DSMX®technologyequippedaircrafttransmittertothereceiverforproperoperation.
Transmitter and Receiver Binding
Throttle Hold
Throttle hold only turns off the motor on an electric helicopter. You maintain
pitch and direction control.
The blades will spin if throttle hold is OFF. For safety, turn throttle hold ON any
timeyouneedtotouchthehelicopterorcheckthedirectioncontrols.
Throttle hold is also used to turn off the motor if the helicopter is out of control,
in danger of crashing, or both.
Please refer to your transmitter manual for more information on programming
throttle hold.
