BNF BLADE 450 X - Transmitter Setup: DX8; Spektrum DX8 Configuration

7
EN
SYSTEM LIST
FUNCTION LIST
Spektrum DX8
SERVO SETUP
TRAVEL SUB TRIM* REVERSE SPEED
THROTTLE 100 100 THROTTLE 0 THROTTLE N THROTTLE NORM
AILERON 100 100 AILERON 0* AILERON N AILERON NORM
ELEVATOR 100 100 ELEVATOR 0* ELEVATOR N ELEVATOR NORM
RUDDER 100 100 RUDDER 0* RUDDER R RUDDER NORM
GYRO 100 100 GYRO 0 GYRO N GYRO NORM
PITCH 100 100 PITCH 0 PITCH N PITCH NORM
AUX2 100 100 AUX2 0 AUX2 N AUX2 NORM
AUX3 100 100 AUX3 0 AUX3 N AUX3 NORM
D/R AND EXPO
POS D/R D/R EXPO SW
AILERON 0 100 100 0 AILED/R
AILERON 1,2 85 85 0 AILED/R
ELEVATOR 0 100 100 0 ELEVD/R
ELEVATOR 1,2 85 85 0 ELEVD/R
RUDDER 0 100 100 0 RUDDD/R
RUDDER 1,2 85 85 0 RUDDD/R
GYRO
SW FMode
CH Gear
NORMAL/POS0 54
STUNT1/POS1 54
STUNT2/POS2 54
HOLD 54
TIMER
MODE Countdown
TIME 4:00Tone/Vibe
START Throttle Out
POS 25
THROTTLE CURVE
LOW 25% 50% 75% HIGH EXPO
N 0 30 60 60 60 INH
1 100 100 100 100 100 INH
2 100 100 100 100 100 INH
H 0 0 0 0 0 INH
TAIL CURVE
LOW 25% 50% 75% HIGH EXPO
N 0 0 0 0 0 INH
1 0 0 0 0 0 INH
2 0 0 0 0 0 INH
H 0 0 0 0 0 INH
PITCH CURVE
LOW 25% 50% 75% HIGH EXPO
N 30 40 50 75 100 INH
1 0 25 50 75 100 INH
2 0 25 50 75 100 INH
H 0 25 50 75 100 INH
Model Type Swash Type Switch Select F Mode Setup Trim Step Warnings Frame Rate
Helicopter 1ServoNormal AllSwitchesINH FlightMode—FMode THR 5 Throttle —Over 10 11ms
Hold — Hold AIL** 0 Stunt1—Act DSMX
ELE** 0 Stunt2—Act
RUD**0 Hold—Act
RTRIM0 Alarm—Tone/Vibe
LTRIM0
TYPE Common
THROTTLE CUT
INHIBIT
SWASHPLATE
INHIBIT
GOVERNOR
INHIBIT
Transmitter Setup
**Changing trim step to zero disables the trim for that channel.
*Neverusesub-trimsortrimsonAILE,ELEVorRUDDchannelswiththeAR7200BX.
