Page 4
Specifications
The E3 CNC Engraver has the following features:
• Rigid laser cut frame.
• Fully supported rail system with SG20U bearings.
• GT2 belt drive on X and Y axis.
• 5/16-18 coupler nut on the Z axis.
• Home switches on all axes.
• MDF Spoilboard with 1/4-20 threaded inserts.
The assembled footprint:
Length: 24.8" (630 mm)
Width: 25.2" (640 mm)
Height: 18.9" (480 mm)
Assembled Weight:
25 lbs.
Cung Area:
X: 17.7" (450 mm)
Y: 15.3" (390 mm)
Z: 3.3" (85 mm)


  your    
      

Routers have a high voltage power supply. Router bits spin at 30,000 rpm
and have cung edges that are hazardous. The operator should understand
these hazards and take appropriate safety precauons before operang the
Router.


