BobsCNC E3 - Y Carriage Installation Instructions

Page 65


  
1 1 Gantry & Frame Assembly
2 2 Y Carriage Assembly
3 2 Y Rail Stops










  
A 4 M4 x 25 Screws
B 4 M4 x 25 Nuts
C 2 8mm Rods
D 2 Switches
E 1 Spiral Wrap
F 2 M2.5 x16 Screws
G 2 M2.5 Nuts
