BobsCNC E4 - Gantry Assembly and GT2 Pulley Instructions

Page 59






-
-
  
1 1 Assembled Gantry
2 3 Stepper Motors
3 2 Switches
4 1 Controller
5 2 10 Small Zip Ties
6 3 GT2 Pulleys
7 1 Spiral Wrap
8 4 M2.5 x 16
9 12 M3 x 10 Screws
10 4 M2.5 Nuts
1
2
3
5
8
7
6
9
4
10
7
