Page 68


  
1 1 Gantry & Frame Assembly
2 1 YZ Carriage Assembly
3 2 Y Rail Stops
  
A 4 M4 x 25 Screws
B 4 M4 x Nuts
C 2 M2.5 x 16 Screws
D 2 M2.5 Nuts
E 1 Spiral Wrap
F 1 Switch
G 2 Y Rails
