Note that the X1 Stepper orientaon is opposite the others. (the red wire is on
the le in the diagram and picture).
Home switch wires do not have polarity. The home switches are connected to
the X , Y , and Z + as shown in orange in the diagram.
The red squares in the diagram are jumper connectors
-
