BOCI BLT481 - Non-Bus Systems

BLT481 Product Manual
8
4.2 Non-bus systems
BCL4500A
Cypcut
IPC
master
station
Slaves
Station
Power
24VDC
Notice:
 The above wiring operations should only be performed by trained and professional personnel.
 When the cutting head is connected to the BCL4500A, the BCL4500A must be powered off.
PWE line
HC plug-in cable
BLT421 cutting head installation
wiring diagram
