ASSEMBLY INSTRUCTIONS
Page
F500
F500-092007
Cable to constitute illustration
11
LEG EXTENSION CABLE (107)
LEFT ATTACHMENT CABLE (108)
3540mm
1765mm
Stamped Eye End
Chain End
Big Ball End
Chain End
107
108
