Body Solid F500 - Detailed Hardware Visuals; Allen and Hex Head Bolt Visuals

F 5 0 0 H A R D W A R E
( s h o w n i n a c t u a l s i z e )
KEY # 02 ALLEN HEAD BOLT M10X115L PARTIAL THRERD QTY.3
KEY # 03 ALLEN HEAD BOLT M10X125L PARTIAL THRERD QTY.4
KEY # 04 ALLEN HEAD BOLT M10X12L FULL THRERD QTY.4
KEY # 05 ALLEN HEAD BOLT M10X15L FULL THRERD QTY.7
40
20
60
80
100 140
160
120
F500-092007
Page
KEY # 10 ALLEN HEAD BOLT M8X10L FULL THRERD QTY.5
KEY # 11 ALLEN HEAD BOLT M8X15L FULL THRERD QTY.2
