F 5 0 0 H a r d w a r e L i s t ( c o n t i n u e d )
Part numbers are required when ordering parts.
KEY#
QTY
PART# DESCRIPTION
99
1 T-SHAPED POP PIN
100 4 WASHER M10 X Φ19
101 86 WASHER M10 X Φ27
102 2 WASHER M12 X Ø34
103 11 WASHER M8 X Φ18
104
1 HEX HEAD BOLT M10 X 50L PARTIAL THREAD
118
2 PLASTIC PAD 30 X 42
119 8
SELF-DRIVEN CROSSHEAD SCREW M4 X 10L
FULL THREAD
121 1 CHROME PLATE
122 1
ALLEN HEAD BOLT M10 X 60L PARTIAL
THREAD
KEY#
QTY
PART# DESCRIPTION
111 2
ARTICULATING FUNCTIONAL TRAINING HARNESS
112 2
FOAM GRIP 1 1/2" OD X 8 1/2"L (low row bar)
113 2
FOAM GRIP Φ34 OD X 540L (lat bar)
114 1 LAT BAR
115
1 LAT BAR PAD
116
1LOW ROW BAR
117 1 LEG HARNESS
A c c e s s o r i e s L i s t
KEY#
QTY
PART# DESCRIPTION
105
1 FUNCTIONAL TRAINING ARM CABLE 3028mm
106
1 LAT PULLDOWN CABLE 5425mm
107
1
LEG EXTENSION CABLE 3540mm
108
1
LEFT ATTACHMENT CABLE 1765mm
109 1 SHORT CABLE 775mm
110
2 TURNPLATE CABLE 523mm
120
1 RIGHT ATTACHMENT CABLE 3435mm
C a b l e L i s t
