Body Solid F500 - Hardware Components Listing

F 5 0 0 H a r d w a r e L i s t
Part numbers are required when ordering parts.
KEY#
QTY
PART# DESCRIPTION
1
3
ACORN CAP NUT M6 preinstalled
2
3
ALLEN HEAD BOLT M10 X 115L PARTIAL THREAD
3
4 ALLEN HEAD BOLT M10 X 125L PARTIAL THREAD
4 4 ALLEN HEAD BOLT M10 X 10L FULL THREAD
5
7
ALLEN HEAD BOLT M10 X 15L FULL THREAD
620
WEIGHT PLATES
7
1 WEIGHT STACK LANYARD
8
1
WEIGHT STACK PIN Φ10 X 138L
9
2
WEIGHT STACK SHIM 50 X 50
10
5
ALLEN HEAD BOLT M8 X 10L FULL THREAD
11 2 ALLEN HEAD BOLT M8 X 15L FULL THREAD
12 1 ALLEN SCREW M4 X 8L FULL THREAD
13
2
ALLEN SCREW M5 X 10L FULL THREAD - preinstalled
14
10
ALLEN SCREW M5 X 5L FULL THREAD
15 6
ALLEN SCREW M8 X 6L FULL THREAD
16
2 ALLEN SCREW M8 X 8L FULL THREAD
17 2
BEARING BUSHING Φ20 X 46L
18
2
BEARING BUSHING Φ37 ID X Φ42 OD - preinstalled
19
2
BEARING BUSHING Φ37 ID X Φ50 OD - preinstalled
20 2
BEARING Φ12 ID X Φ32 OD - preinstalled
21 2
BEARING Φ20 ID X Φ42 OD - preinstalled
22 4
BEARING Φ30 ID X Φ37 OD - preinstalled
23
1 CABLE END SHAFT
24 2 CHROME COLLAR Φ26 ID X Φ35 OD
25
2 TAPERED CROSSHEAD SCREW M5 X 10L FULL THREAD
26
4 CONVEX END CAP 1" X 2"
27 2 CONVEX END CAP 30 X 70
28
5
CONVEX END CAP 40 X 80
29 4 CONVEX END CAP 50 X 100
30
1
CONVEX END CAP 50 X 50
31 3 CROSSHEAD SCREW M4 X 6L FULL THREAD
32 2 FLAT END CAP 30 X 60
33
1 CHROME COLLAR Φ26 ID X Φ38 OD
34
1 FLAT END CAP 40 X 40
35
2 FLAT END CAP 45 X 45
36
1 FLAT HEAD POP PIN 124L
37
1
FLAT HEAD POP PIN 124L (back pad angle adjuster)
38
1 FLAT HEAD POP PIN 138L
39
1
FLAT HEAD POP PIN 96L (back pad position adjuster)
40
2
FOAM GRIP Φ34 OD X 545L (seated press)
41 6 FOAM ROLLER 4" X 8"
42 2 FOOT CAP 50 X 100
43
1 FUNCTIONAL TRAINING COVER
44 1 HEX HEAD BOLT M10 X 110L PARTIAL THREAD
45
2 HEX HEAD BOLT M10 X 85L PARTIAL THREAD
46
1 HEX HEAD BOLT M10 X 60L PARTIAL THREAD
47
16
HEX HEAD BOLT M10 X 45L PARTIAL THREAD
48
2 HEX HEAD BOLT M10 X 55L PARTIAL THREAD
49
1 HEX HEAD BOLT M10 X 70L PARTIAL THREAD
