Body Solid F500 - Parts and Hardware Identification; Mainframe Parts Identification

F 5 0 0 M a i n f r a m e P a r t s L i s t
Part numbers are required when ordering parts.
P a d s L i s t
KEY#
QTY
PART# DESCRIPTION
A 1 MAIN BASE FRAME
B 1 REAR UPRIGHT FRAME
C1 MAIN TOP FRAME
D
1
PULLY HOLDER WITH STOP
E
1
REAR LEG
F 1 SEATED PRESS ARM
G 2 CHROME GUIDE ROD
H 4 CONTOURED BACKING PLATE 170L
I1
ROLLER BAR (1"X535L)
J
1
ROLLER BAR (1"X500L)
K 1 PRESS ARM SUPPORT
L 1 PIVOTING BACK REST FRAME
M 2 WEIGHT STACK SUPPORT FRAME
N
1MAIN FRONT FRAME
O
1
BACK PAD ADJUSTER
P 1 HOLDER FOR DOUBLE PARALLEL PULLIES
Q
1 ADJUSTABLE SEAT FRAME
R2 PULLY HOLDER
S1 LEG HOLD DOWN FRAME
T 1 FUNCTIONAL TRAINNING ARMS PIVOT BASE
U
1 HOLDER FOR DOUBLE CROSSED PULLIES
V 1 SIDE LEG HOLD DOWN FRAME
W1
FUNCTIONAL TRAINING ARM (left side)
X1
FUNCTIONAL TRAINING ARM (right side)
Y
1
SELECTOR ROD
Z
1
LEG EXTENSION ARM
AA 1
FUNCTIONAL TRANING ARMS REAR PULLY
SUPPORT
AB 1 FRONT SHROUD
AC 1 BACK SHROUD
AD 1 PRESS ARM STOP
AE 1
LAT PULL DOWN BAR HOLDER (left side)
AF 1
LAT PULL DOWN BAR HOLDER (right side)
AG 1 LEFT ARMREST
AH 1 RIGHT ARMREST
AI
1
PIVOTING BUSHING
KEY#
QTY
PART# DESCRIPTION
BA
1
SEAT PAD
BB
1
BACK PAD
