Body Solid F500 - Page 19

Part numbers are required when ordering parts.
KEY#
QTY
PART# DESCRIPTION
50
12 HEX HEAD BOLT M10 X 75L PARTIAL THREAD
51
1 HEX HEAD BOLT M10 X 65L PARTIAL THREAD
52
2 HEX HEAD BOLT M8 X 50L PARTIAL THREAD
53
2
HEX HEAD BOLT M8 X 55L PARTIAL THREAD
54
1
HYDRAULIC SEAT ADJUSTER-preinstalled
55
1JAM NUT 1/2"
56 2 JAM NUT 3/8"
57
2
JAM NUT M10
58
2 NYLON BUSHING 40 X 80
59
1 NYLON BUSHING 60 X 60
60 46
NYLON LOCK NUT M10
61
4
BEARING Φ15 ID X Φ32 OD
62
12 NYLON WASHER 3"
63
2
OILITE BUSHING 1"ID X 45 OD - preinstalled
64
2
OILITE BUSHING 1/2" ID X 21 OD - preinstalled
65 1 NAMEPLATE
66 1 NAMEPLATE SEAT
67
4 PULLY SPACER Φ16 X 12L
68 6
PULLY SPACER Φ16 X 21.5L
69 6
PULLY SPACER Φ16 X 42L
70
1PULLY Φ110
71
25 PULLY Φ110
72 2
PULLY Φ90
73 6
ROLLER END CAP
74
2
ROUND END CAP 1"
75
2
RUBBER DONUT Φ63.5
76 3 RUBBER PAD 38 X 40
77 2
RUBBER STOP 58.5L (3/8" bolt)
78
1
SELECTOR ROD (20 selector holes)
79
1 SELECTOR ROD TOP BOLT
80
1 SHAFT 1" X 196L
81
2 SHAFT COLLAR
82
1
SHAFT Φ12 X 122L
83
1
SHAFT Φ20 X 138L
84
1
RUBBER PAD 95 X 140
85
2
FOAM GRIP Φ34 OD X 340L
86 4 SNAP LINK
87 1 SOCKET HEAD BOLT 3/8" X2" PARTIAL THREAD
88
1 SOCKET HEAD BOLT M8 X 10L FULL THREAD
89
2 SPACER SLEEVE Φ16 X 39L
90
1 SPRING LOCK WASHER 1/2"
91
1 SPRING LOCK WASHER 3/8"
92
4 SPRING LOCK WASHER M8
93
1 HEX HEAD BOLT M10 X 25L FULL THREAD
94 58
STEEL BALL (Φ3) - preinstalled
95
1
TOP PLATE 10lbs
96
2
NYLON LOCK NUT M12
97 1
TORSIONAL SPRING (left)- preinstalled
98 1
TORSIONAL SPRING (right)- preinstalled
F 5 0 0 H a r d w a r e L i s t ( c o n t i n u e d )
