Body Solid F500 - Assorted Screw and Bolt Visuals

F 5 0 0 H A R D W A R E
( s h o w n i n a c t u a l s i z e )
40
20
60
80
100 140
160
120
F500-092007
Page
KEY # 44 HEX HEAD BOLT M10X110L PARTIAL THREAD QTY.1
KEY # 45 HEX HEAD BOLT M10X85L PARTIAL THREAD QTY.2
KEY # 46 ALLEN HEAD BOLT M10X60L PARTIAL THRERD QTY.1
KEY # 25 TAPERED CROSSHEAD SCREW M5X10L FULL THREAD QTY.2
KEY # 31 CROSSHEAD SCREW M4X6L FULL THREAD QTY.3
