Body Solid F500 - M10 and M8 Bolt Visuals

F 5 0 0 H A R D W A R E
( s h o w n i n a c t u a l s i z e )
KEY # 47 HEX HEAD BOLT M10X45L PARTIAL THREAD QTY.16
KEY # 48 HEX HEAD BOLT M10X55L PARTIAL THREAD QTY.2
KEY # 49 HEX HEAD BOLT M10X70L PARTIAL THREAD QTY.1
KEY # 50 HEX HEAD BOLT M10X75L PARTIAL THREAD QTY.12
KEY # 51 HEX HEAD BOLT M10X65L PARTIAL THREAD QTY.1
KEY # 52 HEX HEAD BOLT M8X50L PARTIAL THREAD QTY.2
40
20
60
80
100 140
160
120
F500-092007
