9
27
STEP
Diagram 1
Cable Installation
3 1/2” diameter pulley
Start at high pulley station by
inserting the Metal Ball End here.
High Pulley
Cable
Diagram 2
Pulley Installation
3 1/2” diameter
pulley
Diagram 3
Shroud Installation
