Dimensions
The room layout diagram below will help you decide the best placement for your G3S.
The dimensions of the G3S are: width 3’ 7” X length 6’ 8”, the length is adjustable up to 7’ 3”
The ceiling height requirement for the G3S is 7’.
The usage space is: width 5’ X length 11’ 1” (The usage space is the overall space needed for operation.)
The usage space needed for the G3S could be more, depending on the user, allow enough room for the Low Row Station.
Dimensions
11’ 1”
5’
Height
7’
minimum usage
space
6’ 8” - 7’ 3”
3’ 7”
6
adjustable
