Body Solid G3S - Hardware Parts List

Part numbers are required when ordering parts.
KEY# QTY PART# DESCRIPTION
75
Continued on next page
G3S Hardware List
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
1
4
8
5
6
2
4
1
6
1
2
3
2
3
12
4
4
11
6
1
1
1
1
1
1
15
2
6
1
2
2
2
2
2
1
1
1
1
1
JACN.19
JFEC1.75
JCEC2.5
JCEC1.8
JCEC12
JFC22
JNB22
JFL22
JFREC2.5
JRP2450
JRD2.5
JWSS22
JSC1.37X.75
JPP3.5W.75
JPB.56X.37
JSNAP3
JSB.5
JPP4.25W.75
JFOAM48
JTP10
JSR20
JSRTB.5
JHEX.37X.87FTB
JWSW.5
JJN.5
JSP10
JWSR4.87
JREC1.25
JSH3X.5
JRAB.25X.56FTB
JWSW.25X.62
JRR1.37X1.125
JB1.25X.5
JHEX.37X3.25FTB
JWB
JWBH
JWBB
JAS.125X.25
JCES.75
ACORN CAP NUT 3/16” ID -PREINSTALLED
FLAT END CAP 1 3/4” x 1 3/4”
2” X 2” X 2.5” CONVEX END CAP
2” X 2” X 1.8” CONVEX END CAP
1” X 2” CONVEX END CAP
FOOT CAP 2” X 2”
NYLON BUSHING 2” X 2”
FRAME LEVELER 2” X 2”
FOAM ROLLER END CAP 2.5” OD X 1” ID
RUBBER PAD 1 1/2” X 1 1/2”
RUBBER DONUT 2 1/2”
WEIGHT STACK SHIM 2” X 2”
SHAFT COLLAR 1 3/8” OD 3/4 ID 1.5” L
PLASTIC PULLEY 3 1/2” X 3/4”
PULLEY SPACER 9/16” OD X 3/8” ID X 5/8” L (15mm X 9mm X 17mm)
SNAP LINK 3 1/4”
SPACER SLEEVE 1/2” OD X 7/16” ID X 7/8” L
PLASTIC PULLEY 4 1/4” X 3/4”
FOAM ROLLER 4” X 8”
TOP PLATE (10 lbs.)
SELECTOR ROD (20 selector holes)
SELECTOR ROD TOP BOLT 1/2” X 2” FULL THREAD
HEX HEAD BOLT 3/8” X 7/8” FULL THREAD
SPRING LOCK WASHER 1/2”
JAM NUT 1/2”
WEIGHT PLATE 10lbs
WEIGHT STACK RISER 4 7/8”L
ROUND END CAP 1”
SHAFT 3” X 1/2”
ROUND ALLEN BOLT 1/4” X 9/16” FULL THREAD
WASHER 1/4” ID X 5/8” OD
RETAINING RING 1 3/8” OD X 1 1/8” ID
BUSHING 1 1/4” OD X 1/2” ID
HEX HEAD BOLT 3/8” X 3 1/4” PARTIAL THREAD
WATER BOTTLE
WATER BOTTLE HOLDER
WATER BOTTLE BRACKET
ALLEN SCREW 1/8” X 1/4”
CABLE END SHAFT 3/4” L
