Adjustments
3. BACK PAD (U) ADJUSTMENT
A. Grasp Back Pad (U).
B. Turn the T-Shaped Pop Pin (79) in Back Pad Holder (G) counter clockwise to unlock it,
and then pull the Pop Pin to release the Adjustable Back Pad Frame (T). Adjust the
Back Pad to the desired position.
C. Release the T-Shaped Pop Pin (79) and make sure it is fully
engaged into the selector
hole in the Adjustable Back Pad Frame (T). Turn T-Shaped Pop Pin (79) clockwise to
lock it in place.
D. For certain exercises you may wish to change the angle of the Back Pad.
Pull the Flat Pop Pin (78) on the Adjustable Back Pad Frame (T), this will release the
Back Pad Frame (S). Change to the desired angle.
E. Release the Flat Pop Pin (78) and make sure it is fully
engaged into the selector
hole in the Back Pad Frame (S).
38
