30 "Hexagon large at head half-tooth bolt" M10×35×20 3
31 "Hexagon large at head half- tooth bolt" M10×65×20 2
32 hexagon lock nut M10 1
33 at washer Φ10 1
34 at washer Φ8 1
35 communication line "SM5PIN/SM4PIN/L-750mm/26#" 1
36 photoelectric sensor L-500 2
37 "3330EAcontroller (ERP)" 1-20KM/H/incline(ERP) 1
38 power connection cable L-300mm/1.5mm2/(red) 1
39 power connection cable "L-300mm/1.5mm2/(black)" 1
40 rocker switch KCD4 1
41 Self-resetting switch "10A/ABR21-16/250VAC" 1
42 power connection cable L-100mm/1.5mm2/(red) 1
43 power plug 3×1.0mm2×2000 1
44 3330EA front roller Φ88×Φ50×Φ17×606 1
45 3330EA rear roller Φ50×Φ17×529×578 1
46 motor Φ32/36 1
47 incline motor (195mm) 1
48 3330EA running deck 1300×604×t18 1
49 running belt 2930×500×t1.6 1
50 motor belt PJ6 1
51 3330EA motor cover 1
52 rear cover 673×93×51 1
53 side rail 87×34.5×1342 1
54 wheel Φ62×Φ8.0×t22 1
55 cushion 2
56 Round guide block Φ25×φ5×4.5 2
57 pipe strap Φ16 (white) 6
58 EVA pad t15×30×30 10
59 magnet ring 3
60 cable clip 1
61 power cable clip 1
62 upright post L welds 1
63 upright post R welds 0.32 m
