BODYMAX Walking Pad WP60 - Parts List

1 Straight-neck rivet φ6*33 Blue-white zinc plating 2
2 Wheel φ56*25,Soft material TPU with translucent orange,
hard material PP with PANTONE 1375 U color
2
3 Cross pan head tapping screw ST4.2*15 ROHS blue-white zinc plating 41
4 Plastic buckle PA66, original color 3
5 Power cord cover set 50*30*18*3, hard material PA6, soft material TPU,
VD127, 425U
1
6 Wheel bracket 55*51*3, PA6+15GF , Black colour 2
7 Front motor cover 540*119*83*3, ABS, VDI27,425U 1
8 Air channel PP, Black Colour 1
9 Cross pan head tapping screw ST2.9*9 C type ROHS Blue-white zinc plating 56
10 Cooling fan 12VDC,5025,Cable length 650mm 1
11 Cross pan head tapping screw ST3.5*35 ROHS Blue-white zinc plating 4
12 Switch bracket 70*33*16*2.5, ABS, black colour 1
13 Swich 3 pole with LED light, 4.8 terminal 1
14 Wire clip LR1/4 7
15 Cross round head self tapping
screw with washer
ST2.9*9.5 ROHS blue-white zinc plating 12
16 Socket cover ABS, Black Coulor 1
17 Cross countersunk screw M3*15 ROHS Black zinc plating 2
18 3 pole plug 250VAC10A 1
19 plug bracket 54*49*47, embedded M3 stud, ABS, Black Colour 1
20 Motor 1.0HP,DC180V,3100RPM,Cable length160mm 1
21 Diuser PET; White colour, ;0.1 1
22 Light lm PET; ,Gray-black 0.06 1
23 Top motor cover 512*157*11*3, ABS+PET lm , IML, silver zinc plating 1
24 Grating Silicone; matt black; durometer 70 1
25 Upper control board 140*100*φ5.4*6,0603 7*23*I2.65;7*25*I3.15 1
26 Spacer φ7*6, ABS, Black 6
27 Upper motor cover 544*256*98*3, ABS, VDI27,425U 1
28 Lower control board 1
29 Cross pan head screw M4C12 (full threaded) ROHS blue-white zinc plating 11
30 inductor lter Inductor+Filter+ sheet metal+ magnatic ring
88X52X78
1
28
WP60
8.2 Parts List
No. Name Specication Qty.
