BODYMAX Walking Pad WP60 - Page 30

58 Middle aluminum frame 756*523*46*3.5; ADC12; Φ0.2 sandblasting with
stainless steel sands
1
59 Front walking deck 594*461.5*12, HDF, single-sided melamine 1
60 Button circuit board Wire length 250mm 1
61 Button silicone pad Silicone, original color 1
62 Button 38*38*9*2.5, ABS+PET lm, IML, silver plating 1
63 Right front side strip 554.5*57.5*20*3, ABS, VDI27,425U 1
64 Right front cover 802*96*31*3, ABS+PET lm, IML, silver plating 1
65 Walking belt Diamond pattern 2520*415*1.4 1
66 Front foot 46.7*21.5*14.3, hard material PA6+30GF, soft materi-
al TPU with injected M8 insert, 433U
2
67 Hexagon socket head cap
screw
M5*12 (full wire) 8 .8 grade ROHS blue-white zinc
plating
6
68 Rubber pad 004 40*30*1.3 2
69 Rubber pad 001 80*40*1.3 4
70 Rubber pad 002 40*40*1.3 14
71 Left rear side strip 607*57.5*22*3, ABS, VDI27,425U 1
72 Left rear cover 595.5*27*16*3, ABS+PET lm, IML, silver plating 1
73 Rear foot 47*21.8*15.8, hard material PA6+30GF, soft material
TPU, with injected M6 insert, 433U
6
74 Left end cap 40*29*4.7, ABS, VDI27,425U 1
75 Front bottom cover 772*547*37.8*3, ABS, VDI27,425U 1
76 Rear bottom cover 606*547*35*3, ABS VDI27,425U 1
77 Reinforcing plate 335.6*51.57*3, grade A epoxy board 2
78 Right end cap 40*29*4.7, ABS, VDI27,425U 1
79 Hinge assembly 3# zinc alloy; stainless steel C buckle SUS304 2
80 Rear aluminum frame 592*523*41.5*3.5; ADC12; Φ0.2 sandblasting with
stainless steel sands
1
81 Nylon lock nut M4 nylon locknut; blue-white zinc plating 2
82 Anchor plate SHPC T1.5, white zinc plating 2
83 Cross countersunk screw M4*12, blue-white zinc plating 2
84 Graphite nylon sheet 80*25*0.2, adhesive backing 0.16, black 2
85 Graphite nylon sheet 2 25*10*0.2, double-sided back with 3M adhesive
backing; single sided 0.16, black
2
86 Left rear decorative sleeve φ11*10*2, ABS, VDI27, 425U 1
87 Rear cover 538*55*38*3, ABS+PET lm, IML, electroplated silver 1
88 Right rear decorative sleeve φ11*10*2, ABS, VDI27, 425U 1
30
WP60
