Boeing F4B-1 - Page 36

NUMERICAL LIST OF DRAWINGS
3-1751
3-1752
3-1753
3-1754
3-1755
3-1756
3-1757
3-1758
3-1759
3-1844
3-1845
3-1846
3-1847
3-1848
3-1849
3-1856
3-2010
3-2023
3-2025
3-2028
3-2029
3-2038
3-2093
3-2094
3-3101
3-3104
4-403
4-404
4-409
4-410
4-411
4-412
4-413
4-414
4-416
4-417
4-429
4-606
Frame Assy-CO 2 Bottle Door
Stack Assy-Exhaust No. 3
Support Assy-Tube
Bracket Assy-Cable Stop
Mount Assy-Forward Sight
Strap-Bracket Assy-Bomb Control Pulley
Channel-Foot Rest
Bracket Assy-Bomb Control Pulley
Panel-Switch
Support Assy-Mixture Control Outer
Support Assy-Spark Control
Support Assy-Throttle Control Inner
Step Assy
Screen Assy-Fuel Tank
Clip A, ssy-Fire Exting. Handle Supp.
Tube Assy-Oxygen High Pressure
Gauge Assy-Fuel Sight
Pad Assy-50 Cal. Buffer
Strap Assy-Fuel Tank Forward
Fitting-Sta. 8 Brace Tube
Frame Assy-Aileron Roller Insp.
Kit Assy-Tool
Vent Assy-Oil Tank
Bracket Assy- Flotation Pulley
Receptacle Assy-Gas Gauge Light
Bracket-Gas Gauge Light Sw.
Tube Assy-Stab. Gear Torque
T'ube Assy-Blast. Machine Gun
Strut Assy-Sta.16-A Lower Comp.
Strut Assy-Sta. 12-A Comp.
Strut Assy-Sta. A Comp.
Oleo Assy
Strut Assy-Landing Gear Drag
Strut Assy-Compression
Spacer Assy-Flying and Land. Wire
Oleo Assy-Arresting Gear
Hook Assy-Arresting Gear Axle
Door Assy-Crank Support
62
NUMERIC , AL LIST OF DRAWINGS
5-442
5-443
5-445
5-446
5-449
5-450
5-451
5-452
5-453
5-544
5-455
5-456
5-458
5-459
6-803
6-825
6-826
6-952
6-955
6-956
6-957
6-958
6-959
6-960
6-961
6-965
6-966
6-968
6-969
6-998
6-999
6-1102
6-1104
6-1105
6-1106
6-1107
6-1109
6-1111
6-1112
6-1113
6-1114
6-1115
6-1117
6-1119
6-1220
Rib Assy-No. 24 Upper
Strut Assy-Upper-Comp.
Strut Assy-Sta. 6-A
Beam Assy-Bottle Support
Rib Assy-No. 13 Upper
Rib Assy-No. 14 Upper
Rib Assy-No. 15 Upper
Rib Assy-No. 16 Upper
Rib Assy-No. 17 Upper
Rib Assy-No. 18 Upper
Rib Assy-No. 19 Upper
Rib Assy-No. 20 Upper
Rib As • sy-Sta. 1 and 12 Upper
Fixed Equipment
Reel Assy-30 Cal. Amm.
Reel Assy-30 Cal. Amm.
Reel Assy-50 Cal. Amm.
Fitting Assy~Upper Outer Front
Joint As-sy-Sta. No . 4 Lower
Chute Assy-.30 Cal. Ejection
Joint Assy-Sta. No. 3 Upper
Chute Assy-30 Cal. Ejection LH
Housing Assy-50 Cal. Amm. Reel
Housing Assy-30 Cal. Amm. Reel
Housing-Arum. Reel
Hinge Assy-Front Lower
Seat Assy- Pilots
Axle Assy-Landing Gear
Axle Assy- Landing Gear
Hinge Assy-Axle
Frame-Windshield
Bracket Assy-Starter Crankshaft
Shutter-Nose Cowling
Cowling-Nose
Cowling Assy-Nose
Hook Assy-Arresting Gear
Mast Assy-Aileron
Control Assy-Bomb Rack Safety
Pedal Assy-Rudder
Tail Skid Install.
Unit Assy-Mixture Control
Unit Assy-Throttle Control
Useful Load
Ring Assy-Nose Cowl Support
Support Assy-Axle Hooks
