Product description 2.1 Technical data
Page 16 Operating instructions for S 40-3...S 150-3 series screw compressors
Technical data S 101-3...S 150-3, part 1
Type S 101-3 S 125-3 S 150-3
Dimensions
- Height (silenced) [inch] 69.3 69.3 69.3
- Height (super silenced) [inch] 88.8 88.8 88.9
- Width (silenced/super silenced) [inch] 95.1 95.1 95.1
– Depth [inch] 51.8 51.8 51.8
Weight
– silenced [lbs.] 4513 4557 4700
– super silenced [lbs.] 4645 4689 4833
Air cooling
Max. sound pressure level [±3 dB(A)]
– silenced / super silenced [dB(A)] 76 / 72 79 / 74 79 / 74
Measurement surface
– silenced / super silenced [dB(A)] 17 / 18 17 / 18 17 / 18
Sound power level
– silenced / super silenced [dB(A)] 93 / 90 96 / 92 96 / 92
Water cooling
Max. sound pressure level [±3 dB(A)]
– silenced / super silenced [dB(A)] 75 / 71 78 / 73 78 / 73
Measurement surface
– silenced / super silenced [dB(A)] 17 / 18 17 / 18 17 / 18
Sound power level
– silenced / super silenced [dB(A)] 92 / 89 95 / 91 95 / 91
Compressor
Max.final compression temperature [°F] + 230 + 230 + 230
Volume flow according to
ISO 1217 appendix C at:
– p
max
= 100 psig [cfm]
504.78 565.29 682.58
– p
max
= 115 psig [cfm]
483.04 540.95 649.70
– p
max
= 125 psig [cfm]
483.04 540.95 649.70
– p
max
= 150 psig [cfm]
421.25 519.41 575.55
– p
max
= 190 psig [cfm]
349.57 432.55 501.40
Drive motor
Rated power [Hp] 101 121 147
Rated speed
– 60 Hz [rpm] 3600 3600 3600
Protection type IP TEFC TEFC TEFC
ISO class F F F
Electrical connection
Mains voltage compressor
1)
[V]
1)
Standard equipment. Mains voltages and frequencies are specified on a plate in the switch cabinet.
460 / 575 460 / 575 460 / 575
Frequency
1)
[Hz]
60 60 60
Fuse protection for 208 V
2)
[A]
---
Fuse protection for 230 V
2)
[A]
2)
Use fuse RK 5 only. The fuse values change in the case of other mains voltages and frequencies.
---
Fuse protection for 460 V
2)
[A]
150 175 200
Fuse protection for 575 V
2)
[A]
125 150 175
