Installation 3.2 Compressor room
Page 34 Operating instructions for S 40-3...S 150-3 series screw compressors
Cooling air requirement
Please refer to the following table for the cooling air requirement and size of
the supply air openings for your compressor Ensure that flaps and weather
protection grids have the necessary free cross section. We generally recom-
mend contacting a specialist company for performing the duct construction
work and planning.
Type Drive
rating
Air cooling
1)
Water cooling
Cooling air
requirement
for free
standing unit
Necessary
inlet opening
for free
standing unit
Cooling air
requirement
for instal-
lation with
ducting
Necessary
free duct
cross-
section
Cooling air
requirement
for free
standing unit
Necessary
inlet opening
for free
standing unit
[Hp] [cfm] [sq. ft.] [cfm] [sq. ft.] [cfm] [sq. ft.]
S 40-3 40 6467 15.0 3237 4.5 1200 2.7
S 50-3 50 7651 17.5 3825 5.2 1200 2.7
S 60-3 60 7651 17.5 3825 5.2 1200 2.7
S 61-3 60 7651 17.5 3825 5.2 1200 2.7
S 75-3 74 9418 22.0 4709 6.4 1200 2.7
S 100-3 101 10830 25.0 5415 7.4 1200 2.7
S 101-3 101 11772 27.0 5886 8.0 2000 4.9
S 125-3 121 18834 44.0 9417 12.7 2000 4.9
S 150-3 147 18834 44.0 9417 12.7 2000 4.9
SF 60-3 60 7651 17.5 3825 5.2 1200 2.7
SF 100-3 101 10830 25.0 5415 7.4 1200 2.7
SF 150-3 147 18834 44.0 9417 12.7 2000 4.9
1)
The cooling air requirement is based on a 7°F-difference between the ambient temperature and the outside temperature.
Table 3.1: Cooling air demand, cross-sections of openings and ducts required
