EN
23
01 Contents of the Box
n
1 x GlassBuddy
n
1 x Carrying case
n
1 x Brief operating instructions
n
1 x USB stick with operating
instructions and PC software
n
1 x USB cable 2.0, A / Micro B
02 Features of the
GlassBuddy Basic /
GlassBuddy Plus
n
Destruction-free analysis of glass, even when
installed
n
Measuring monolithic glass with a thickness
between 2.6 mm and 19 mm
n
Analysis of laminated glass, multi-laminated
glass, fire protection glass (GlassBuddy Plus
only), 1-gap and 2-gap insulating glazed units
n
Measuring glass compounds of 50 mm
(GlassBuddy Basic) or 100 mm
(GlassBuddy Plus), see also chapter 12
n
Recognition of PVB films (up to a max. of 8 films
per compound), indication of their thickness and
position
n
Recognition of up to 3 coatings and
determination of the coating position
n
Accuracy: 0.1 mm, tolerance: 1% on measuring
range
n
Storage of up to 250 measuring results
n
USB interface
n
Simple and self-explanatory menu operation,
graphic display
n
High quality Li-ion battery for up to 8 hours of
continuous operation
03 The Keypad
Despite the numerous functions of the GlassBuddy,
only a few keys are needed. The user interface is
intuitive and can be learned quickly and easily. This
chapter explains the functions of the individual keys.
Press
n
to switch the GlassBuddy on
n
to start measuring
n
to save the results after the measurement
n
to confirm input
n
to delete the current result
n
to quit the menu
n
to interrupt the deletion of saved data
n
to delete error messages
n
to go to the menu
n
to scroll through the measuring results
n
to scroll through the menu
n
to adjust date and time
n
to switch on the light
See chapter 12 Glass Types and Measuring Ranges
