Bolin Technology KBD-1010 - Connection; Power

10
Connection
The controller supports serial RS232/RS422 and IP Cross protocol mix-control. It allows you to use
RS232/RS422/IP control on one controller to control cameras (Protocol support: VISCA, PELCO D/P, ONVIF,
VISCA over IP, CGI*) in a single system.
IP port to network switch


o
o
RS232 Connection
 RS232 Connection

RS422 Connection


Power
o
o
o
o
o
o
o
