13
English
2 - Preparation for use
Fitting with standard capscrew DIN912:
5 6 7
236 803 03 010 236 803 03040 M3 x 45 12.9
236 803 04040
236 803 05040
236 803 06040
NA
M4 x 55 12.9
M5 x 60 12.9
M6 x 65 12.9
M8 x 65 12.9
236 803 04 010
236 803 05 010
236 803 06 010
236 803 08 010
M3
M4
M5
M6
1 + 2 + 3 + 4
M8
COMMON
ADAPTATOR
8
46 7 52 1 3
Adjusting the position of the anvil in relative to the mandrel
• The position of the anvil depends on the length of the Rivet Nut
®
before
setting.
• The
position of the anvil should be adjusted as shown in figure 5.
• After adjustment, tighten the anvil locknut (2) to 10 Nm.K
OPEN Rivet Nut
®
SEALED Rivet Nut
®
Flush rod
on
the
end
of
the
Rivet Nut
®
Thread root single-turn rod
Figure 5 - Adjustment of the anvil position
