Fig. 53
● Remove the crankcase ventilation socket (Fig.
53).
Fig. 54
● Unscrew the oil shut-off valve (Fig. 54).
Fig. 55
● Take the locking plate (Fig. 55) off.
Fig. 56
● Screw the pressure valve holder 1 (Fig. 56) on
with the O-ring (2).
● Remove filling piece (3), spring (4), seal ring
(5) and pressure valve (6).

Caution
After pressing the pump element out hold the
control sleeve (9) so that it does not drop into
the engine case!
Fig. 57
● Unhook the pump piston (Fig. 57) from the
rocker arm to the injection pump.
