Bomag BPR 45/55 D - Loading and Transport

Operation
BOMAG 33BPR 45/55 D, BPR 55/65 D
5.9 Loading/transport
Danger!
Danger of accident! Life hazard!
Make sure that persons are not endangered by
the machine tipping or sliding off.
Use only safe lifting gear of sufficient load
bearing capacity Minimum lifting capacity of
lifting gear: see operating weight in chapter
"Technical Data".
Loads must only be attached and hoisted by
an expert (capable person).
For lifting the machine attach the lifting gear
only to the lifting eye provided for this pur-
pose.
Check lifting eye for damage before use. Do
not use a damaged or in any other way im-
paired lifting eye.
Do not lift or lower the machine jerkily.
The tension must always be effective in verti-
cal direction.
The machine must not swing about when be-
ing lifted.
Do not step or stand under suspended loads.
Always use suitable lashing gear on the lifting
points to lash down the machine.
Lash the machine down, so that it is secured
against rolling, sliding and turning over.
Fig. 35
l Adjust the steering rod upright and engage the
locking lever (Fig. 35).
Fig. 36
l Fold the lifting hook (Fig. 36) up.
Fig. 37
l Always attach the lifting tackle to the lifting eye
to load the vibratory plate (Fig. 37) on a trans-
port vehicle.
l Lash the vibratory plate down to the transport
vehicle, so that it is secured against rolling,
sliding and turning over. Fasten the lashing
tackle at the marked lashing points.
