Trouble shooting
BOMAG 63BPR 45/55 D, BPR 55/65 D
Fig. 78
l Join the plus poles on external battery and
starter battery with the jump wire (Fig. 78).
l Use the second jump start cable to connect
the negative poles on external battery and
starter battery.
l Start the engine as described in the chapter
“Starting the engine”.
l When the engine is running remove the jump
start cable from the two negative poles first
and from the positive poles after.
Note
i
This work sequence is necessary to avoid short
circuit caused by contact between positive and
negative cables.
l Close the hood again and ´fasten it with bolts.
7.3 Fuses
Danger!
Fire hazard!
Do not use fuses with higher ampere ratings
and do not bridge fuses.
Caution
!
Always cover the fuse with the protective cov-
er.
Fig. 79
Fuse (25 A) (Fig. 79).
Caution
!
Machines with Economizer
1
are protected by
an additional fuse (5 A).
1 Optional equipment
