Instruction Manual for F1300/1600 Mud Pump
47
Drawing No.
Item Qty Description
F-1300 F-1600
29
1
Flange
T508-1002 T508-1002
30 1
KB-75 Dampener
AK75350200 AK75350200
31 1
JA-3 Shear relieve valve
AH0000060200 AH0000060200
32 2
Connection tube
T510-1002 T510-1002
33 1
Cover plate
AH1301011800 AH1301011800
34 2
Right-angle joint
T511-1002 T511-1002
35 14
Bolt 1/2-13UNCX1
T500-1001 T500-1001
36 8
Bolt 1/2-13UNCX1 1/2
T500-1017 T500-1017
37 28
Bolt 5/8-11UNCX1 5/8
T500-1010 T500-1010
38 16
Bolt 1-8UNCX3 1/4
T500-1013 T500-1013
39 16
Nut 1-8UNC-2B
T501-1003 T501-1003
40 4
Bolt 5/8-11UNCX1 3/4
T500-1008 T500-1008
41 4
Nut 5/8-11UNC-2B
T501-1002 T501-1002
42 6
Pin for index tag
420999050603001000 420999050603001000
43 16
Spring washer 27 (GB93)
420503011271600000 420503011271600000
44 22
Washer 12 (GB848)
420501036120200000 420501036120200000
45 28
Washer 16 (GB848)
420501036160200000 420501036160200000
46 4
Spring washer 16 (GB93)
420503010161600000 420503010161600000
47 8
Cruciform slot panhead
screw M4x16 (GB818)
420101050704001606 420101050704001606
48 1
Rubber strip
140601061000000000 140601061000000000
49 1
Dual dial anti-knock
pressure gauge
380207192602511514 380207192602511514
50 10ml
Threads anaerobic lock
glue
170506010100243000 170506010100243000
51
On
demand
Adjustable washer
AH13010119 AH13010119
52
8
Plain cushion
420501060270100000 420501060270100000
