Instruction Manual for F1300/1600 Mud Pump
46
F-1300/1600 Drilling Mud Pump
Drawing No.
Item Qty Description
F-1300 F-1600
1
1
Frame assembly
AH1301020100 AH1301020100
2
1
Crank shaft assembly
AH1301020200 AH1601020100
3
1
Pinion shaft assembly
AH1301020300 AH1601020200
4
3
Crosshead assembly
AH1301020400 AH1301020400
5
1
Fluid end assembly
AH1301020500 AH1301020500
6
1
Power end lubrication
assembly
AH1301020600
AH1301020600
7
1
Skid
AH1301020700 AH1301020700
8
1
Spray pump assembly
AH1301020800 AH1301020800
9
2
BS Nameplate
AH13010209 AH16010203
10
1
Tools
AH1301021000 AH1301021000
11
1
Spare parts
AH1301021100 AH1301021100
12
1
Discharge filter assembly
AH1001021100 AH1001021100
13
2
Seal washer
AH10010109 AH10010109
14
1
Ventilation shield
T515-101.00 T515-101.00
15
1
Small crane
AH1301011000 AH1301011000
16
1
Lifting frame
AH1301011100 AH1301011100
17
1
Cover plate
AH1301011200 AH1301011200
18
1
Gasket
AH13010113 AH13010113
19
2
Indicator
AH10010113 AH10010210
20
2
Oil level assembly
AH1001011400 AH1001011400
22
2
Drain cover（Ⅲ）
AH1001011500 AH1001011500
23
2
Seal washer
AH10010116 AH10010116
24
2
Crosshead pore cover
AH13010114 AH16010104
25 2
Gasket
AH13010115 AH13010115
26
1
Transition joint
T512-1002 T512-1002
27
1
Elbow
AH10010212 AH10010212
28
1
Gasket ring R44
T508-1002 T508-1002
To Next Page
