Instruction Manual for F1300/1600 Mud Pump
49
Drawing No.
Item Qty Description
F-1300 F-1600
7
1
Locating ring (I)
AH130101020100 AH130101020100
8
1
Hollow crankshaft
AH1301020201 AH1601020101
9
1
Locating ring (II)
AH1301010203 AH1301010203
10
1
Gear ring
AH1301010204 AH1301010204
11
12
Piston nut 1
1/2-8UN
AH130101020500 AH160101010200
12
12
Bolt 1 1/2-8UNx5
1/2
AH1301020202 AH1601020102
13
2
Spacer ring,
AH1301020203 AH1301020203
14
1
Main bearing
sleeve (left)
AH130102020400 AH130102020400
15
2
Retainer ring
AH1301020205 AH1301020205
16
72
Bolt 5/8-11UNCx1
1/2
AH130101021000 AH160101010400
17
2
Retainer plate
T501-303.0 T501-303.0
18
28
Bolt 5/8-11UNCx1
3/4
T500-2023 T500-2023
19
4
Main bearing bolt
AH1301010211 AH1301010211
20
On
demand
Shim set
AH1301020206 AH1601020103
21
2
Screw 5/8-11UNC
×4
AH1301010213 AH1601010106
22
3
Eccentric bearing
T500-1018K T500-1018K
23
2
Main bearing
AH1301010214 AH1301010214
24
28
Washer 16
(GB848)
T500-1008 T500-1008
25
2
Screw 5/8-11UNC
×4 3/4
AH1301010215 AH1301010215
26
40m
Lock wire φ1.5
(GB343)
AH130101021600 AH130101021600
27
3m
Lock wire φ3
(GB343)
T500-3004K T500-3004K
28
90ml
Threads
anaerobic lock
glue 243
AH1301010217 AH1601010107
