Instruction Manual for F1300/1600 Mud Pump
53
Item No. Qty. Description Drawing No.
8 2
Double lip seal 5"X6.25"X0.625"
AH1301010406
9 1
Locking spring
AH1301010407
10 1
Mud guard plate
AH1301010408
11 1
Crosshead extension rod
AH1301010409
12 1
Crosshead pin
AH1301020403
13 1
O-ring φ125×7 (GB3452.1)
530301011250070007
14 8
Bolt 3/4-10UNCX2 1/2
T500-3010
15 1
Plate gasket
AH1301010411
16 1
O-ring φ160×7 (GB3452.1)
530301011600070007
17 1
Crosshead guide (lower)
AH1301010412
18 1
Crosshead pin retainer
AH1301020404
19 1
Crosshead bearing
AH1301010414
20 2
Pipe connector NPT3/8″×2
AH1301010414
21 2
Bolt 1-8UNCX2 1/4
T500-2018K
22 6
Bolt 1-8UNCX2 1/2
T500-2019K
23 8
Locking plate
AH1301020402
24 4
Bolt 3/8-16UNCX1
T500-1021
25 8
Screw 1-8UNCX2 1/2
T500-3013K
26 4
Spring washer 10 (GB93)
420503011101600000
27
On
demand
Galvanized wire φ1.6 (GB4240)
040104030160000800
30
Threads anaerobic lock glue 243
170506010100243000
