Instruction Manual for F1300/1600 Mud Pump
52
F-1300/1600 Crosshead Assembly
Link
12
22
4
18
23
2
1
19 2426
17
B-B
3027
25
8
27
3025
E
30
30
13
6
I
5
16
E-E
10
11
27
25
B
21
30
20
B
E
155
7
I
9
Item No. Qty. Description Drawing No.
1 1
Crosshead
AH1301020401
2 1
Crosshead guide (upper)
AH1301010402
3 8
Shim set
AH100101041700
4 2
Shim
AH1301010403
5 1
Stuffing box
AH1301010404
6 1
Sealing ring
AH1301010405
7 1
O-ring φ190×3.55 (GB3452.1)
530301011900035507
