Instruction Manual for F1300/1600 Mud Pump
51
Drawing No.
Item Qty Description
F-1300 F-1600
12
16
Bolt 7/8-9UNCX2
T500-1027 T500-1027
13 2 Oil seal
9.125"X10.375"X0.625"
AH1301010311 AH1301010311
14 2 Bearing 4G32844H
AH1301010312 AH1301010312
15 16 Spring washer 22 (GB93)
420503011221600000 420503011221600000
16 24 Spring washer 14 (GB93)
420503011141600000 420503011141600000
17 1 Flange
AH1301010313 AH1301010313
18 3 Bolt 5/8-11UNCX1 3/4
T500-2003 T500-2003
19 3 Spring washer 16 (GB93)
420503011161600000 420503011161600000
To Next Page
