BOMCO F-1300 - Page 56

Item
No.
Qty. Description Drawing No.
1 3
Fluid end Assembly
AH130102050100
2 3
Cylinder head flange
AH1301010502
3 3
Cylinder head
AH1301010503
4 3
Plug assembly
AH130101050400
5 3
Valve rod guide (lower)
AH130101050500
6 3
Cylinder head plug
AH130101050600
7 3
Locating plate
AH1301010507
8 3
Cylinder head seal ring
AH1301010508
9 1
Discharge manifold
AH1301010509
10 6
Valve spring
AH00000101
11 3
O-ring φ95×5.3 (GB3452.1)
530301010950053007
12 6
Valve Assembly API 7 pylome
AH0000020300
13 3
Valve cover seal ring
AH1301010510
14 3
Valve pot cover
AH1301020502
15 6
Liner seal ring
AH1301010512
16 3
Wear plate
AH1301020503
17 3
Liner flange
AH1301010514
18 3
Liner press cover
AH130101051500
19 3
Piston rod
AH1301020504
20 3
Connector tube
AH130102050500
21 3
O-ring φ200×7 (GB3452.1)
530301012000070007
22 3
Liner lock ring
AH1301010518
23 3
Bi-metal liner
AH130102051200
24 3
Clamp assembly
AH130102050600
26 3
Elbow NPT3/8-M22X1.5
AH1301020507
27 3
Liner end cover
AH1301010520
28 3
British piston
AH130102050800
29 18
Bolt 7/8-9UNCX2
T500-1027
30 3
Joint NPT1/2-M22X1.5
AH1301020509
31 3
Right joint NPT1-NPT1/2
AH1301020509
32 1
Suction pipe
AH130102051100
