Instruction Manual for F1300/1600 Mud Pump
56
Item
No.
Qty. Description Drawing No.
33 4
Shim set
AH130101052300
34 30
Gasket 39
AH1001010527
35 3
Valve rod guide
AH1001010510
36 16
Stud bolt 1 1/2-8UNCX10 1/2
T500-7002
37 44
Nut 1 1/2-8UN
T501-2001
38 3
Retainer
AH1001010512
39 12
Bolt 3/8-16UNCX3/4
AH0501020509
40 3
O-ring 41.2x3.55 （GB3452.1）
530301010412035507
41 3
Piston nut 1 1/2-8UN
T501-303.0
42 3
O-ring φ185x7 (GB3452.1)
530301011850070007
43 1
Suction baffle plate
T505-1006
44 3
O-ring φ345x7 (GB3452.1)
530301013450070007
45 2
Suction flange (Ⅰ)
AH1001010525
46 1
Suction flange (Ⅱ)
AH1001020509
47 36
Nut 1-8UNC
T501-1003
48 24
Bolt 1-8uncx3 1/2
T500-1023
49 1
Stainless steel wireφ1.6×1830
（GB4240）
040104030160001900
50 3 Hose assembly C-13X1W-850
（JB1887）
140507011301008530
51 2
Plug NPT 1 1/2
T506-1007
52 12
Stud bolt 1 1/2-8UNX22 1/4
AH1301020513
53
Loktite glue 243
170506010100243000
54 12
Bolt 1-8UNCX4 1/4
T500-1024
55 3
Hose clamp 3 （Q/ZB251）
061401030750000000
56 2
Discharge baffle plate
T505-1008
57
Suction dampener
AH0000050100
