ASSEMBLY INSTRUCTIONS
44 .
CYLINDER VALVE
PRESSURE
RELIEF VALVE
BLEED-OFF
VALVE
BLACK COUPLING NUT
REGULATOR
turn clockwise to connect
turn clockwise
to reseal
connections by hand only.
Make sure it is fastened securely and tighten
by turning the regulator coupling nut clockwise.
regulator from the body (C) to the cylinder valve
close the propane tank. Attach the preassembled
Turn the cylinder valve on the tank clockwise to
5 .
Once the tank is attached to the regulator,
make sure the propane gas tank sits on the
metal stand inside body (C) completely. Turn the
preassembled wing screw on the outer part of
metal stand clockwise to secure the propane gas
tank tightly.
1-866-771-2663 | Page 7
