Boneco H700 - Overview and Part Names; A681 HYBRID Filter; AH700 Evaporator Mat; Water Tank

9
en
1 Front cover
2 Pre-filter
3 A681 HYBRID filter
4 Filter holder
5 Drum
6 AH700 evaporator mat
7 BONECO H700
8 Water tank
9 Fragrance container
10 Water base
11 Fan blade
12 Power supply
OVERVIEW AND PART NAMES
1 2 3 4
5
109 11 12
6 7 8
