Modbus Instruction manual 61
Note: With the use of remote contacts the signal sources* are taken over from
the control word 410. Signals at the hardware contacts (terminals) are not
evaluated by the standard operation modes (e.g. 71 for S2IND).
For the evaluation of terminal signals special operation modes are avail-
able. They are denoted with the additional term “(Hardware)” and num-
bered from 526 to 546.
Exception: The controller release via the hardware contact S1IND (termi-
nal X210A.3) and Bit 0 “S1IND” of the
controlword
must be set.
It is not possible to release the controller only via software.
Signal sources are:
- S1IND ... S6IND,
- MFI1D,
- EM-S1IND ... EM-S3IND
Assignment of parameter
Control Word 410 and actual value Status Word 411:
Control Word 410
Status Word 411
Bit no. Bit no.
Bit no. Bit no.
0
S1IND
0
Ready for being switched on
1 S2IND 1
Switched on
2 S3IND 2
Operation - released
3 S4IND 3
Error
4 S5IND 4
Voltage – disabled*
5 S6IND 5
Quick stop
6 MFI1D 6
Starting lock-out
7 EM-S1IND 7
Warning
8 EM-S2IND 8 –
9 EM-S3IND 9 Remote
10 – 10
Reference value reached
11 – 11
Limit value reached
12 – 12 –
13 – 13 –
14 – 14 –
15 – 15
Warning2
* The logic state is “0” for ACT devices.
