11 Parameter List
The following tables contain parameters which are relevant to the CM-232 and CM-485
communication modules. For the other parameters, refer to the frequency inverter
parameters.
For better clarity, the parameters have been marked with pictograms:
The parameter is available in the four data sets.
The parameter value is set by the SETUP routine.
This parameter cannot be written when the frequency inverter is in operation.
This parameter is not accessible via the control unit KP500 and the control soft-
ware VPlus; it is only accessible via the communication channel.
I
FUN,
U
FUN,
P
FUN
: rated values of the frequency inverter, ü: overload capacity of frequency inverter
11.1 Actual Value Menu (VAL)
Actual Values of the Frequency Inverter
No. Name/Meaning Unit Display range Chapter
228
Internal Reference Frequency
Hz -1000.00 ... 1000.00 9.2.1, 10.2.3
229
Reference Percentage Value
% ± 300.00 9.2.2
249
Active Data Set
– 1 ... 4 9, 10
250
Digital Inputs
– 0 ... 255 9.1.3
260
Current Error
– 0 ... 0xFFFF 9.1; 12.2
270
Warnings
– 0 ... 0xFFFF (bit coded) 9.1; 12.1
282
Ref. Bus Frequency
Hz -1000.00 ... 1000.00 9.2.1, 10.2.3
283
Ref. Ramp Frequency
Hz -1000.00 ... 1000.00 9.2.1, 10.2.3
411
Status Word
– 0 .... 0xFFFF 9; 9.1
11.2 Parameter Menu (PARA)
RS232 / RS485
No. Name/Meaning Unit Setting range Chapter
10
Baud Rate
– 1 ... 6 5.2, 5.3
Inverter Data
11
VABus SST Error Register
– 6.6
34
Program(ming)
– 0 ... 9999 5.2, 5.3
Bus controller
392
State-transition 5
– 0 ... 2
9.1.2.2, 10.2,
10.2.2
RS232 / RS485
394 RS232/RS485 NodeID – 1 ... 30 5.2, 5.3
395
Protocol
– 0 … 3 6
Bus controller
410
Control Word
– 0 ... 0xFFFF 9; 9.1
412
Local/Remote
– 0 ... 44 9; 9.1,10, 10.1
