ANNEX 2 - LUBRICANT CHARGE QUANTITY
N.B. Oil quantities are indicative. Check actual level after filling through the appropriate plug.
Mounting position Mounting position
ATO ATO
300
L1
0.6 1.0 0.9
310
L1
5.0 6.5 6.0
L2
0.9 1.3 1.2
L2
6.3 7.8 7.3
L3
1.2 1.6 1.5
L3
7.1 8.6 8.1
L4
1.5 1.9 1.8
L4
7.4 8.9 8.4
301
L1
0.8 1.2 1.1
311
L1
7.0 12 10
L2
1.1 1.5 1.4
L2
9.0 14 12
L3
1.4 1.8 1.7
L3
10 15 13
L4
1.7 2.1 2.0
L4
11 16 14
303
L1
1.3 2.3 2.0
313
L1
9.0 14 12
L2
1.6 2.6 2.3
L2
12 17 15
L3
1.9 2.9 2.6
L3
13 18 16
L4
2.2 3.2 2.9
L4
13 18 16
304
L1
1.4 2.4 2.2
314
L2
17 25 21
L2
1.9 2.9 2.7
L3
19 27 23
L3
2.2 3.2 3.0
L4
20 28 24
L4
2.5 3.5 3.3
315
L2
19 27 23
305
L1
1.6 2.6 2.4
L3
21 29 25
L2
2.1 3.1 2.9
L4
22 30 26
L3
2.4 3.4 3.2
316
L2
22 30 26
L4
2.7 3.7 3.5
L3
24 32 28
306
L1
2.5 3.5 3.2
L4
25 33 29
L2
3.3 4.3 4.0
317
L2
26 41 36
L3
3.6 4.6 4.3
L3
29 44 39
L4
3.9 4.9 4.6
L4
30 45 40
307
L1
3.5 5.0 4.5
318
L3
40 55 50
L2
4.5 6.0 5.5
L4
43 58 53
L3
5.0 6.5 6.0
319
L3
50 70 60
L4
5.3 6.8 6.3
L4
53 73 63
309
L1
4.0 5.5 5.0
321
L3
56 76 66
L2
5.0 6.5 6.0
L4
60 80 70
L3
5.5 7.0 6.5
L4
5.8 7.3 6.8
