The warning and error messages displayed during the verification process have to be
observed. If a critical condition is detected during the guided commissioning, it is
displayed by the control unit. Depending on the deviation from the expected
parameter value, either a warning or an error message is displayed.
− To ignore the warning or error messages, press the ENT key. The guided
commissioning is continued. However, it is recommended that the data be
checked and corrected if necessary.
− To correct the entered parameter values after the warning or error message,
press the ESC key. Use the arrow keys to switch to the parameter value which is
to be corrected.
Warning Messages
Code Measures / Remedy
SA000
No warning message present. This message can be read out via an
optional communication module.
SA001
The value of the parameter
Rated Voltage 370 is out of the rated voltage
range of the frequency inverter. The maximum reference voltage is
indicated on the nameplate of the frequency inverter.
SA002
The calculated efficiency is in the limit range for a three-phase motor.
Check the values entered for the parameters
Rated Voltage 370, Rated
Current
371 and Rated Mech. Power 376.
SA003
The value entered for parameter
Rated Cosinus Phi 374 is outside of the
normal range (0.6 to 0.95). Check the value.
SA004
The calculated slip for an asynchronous motor is in the limit range.
Check the values entered for parameters
Rated Speed 372 and Rated
Frequency
375.
If an error message is displayed, the rated values must be checked and corrected.
The guided commissioning procedure is repeated until the rated values have been
entered correctly. Aborting the guided commissioning procedure by pressing ESC key
should only be done be expert users because it may be possible that rated values
have not been entered or determined correctly.
Error Messages
Code Measures / Remedy
SF000 No error message exists
SF001
The value entered for parameter
Rated Current 371 is too low. Correct the
value.
SF002
The value for parameter
Rated Current 371 is too high, referred to
parameters
Rated Mech. Power 376 and Rated Voltage 370. Correct the
values.
SF003
The value entered for parameter
Rated Cosinus Phi 374 is wrong (greater
than 1 or smaller than 0.3). Correct the value.
SF004
The calculated slip frequency is negative. Correct the values entered for
parameters
Rated Speed 372 and Rated Frequency 375.
SF005
The calculated slip frequency is too high.
Correct the values entered for parameters
Rated Speed 372 and Rated
Frequency
375.
SF006
The calculated total output of the drive is lower than the rated power.
Correct the value entered for parameter
Rated Mech. Power 376.
SF007
The set configuration is not supported by the guided commissioning. For
parameter
Configuration 30, select one of the configurations described in
these operating instructions.
