ADJUSTING THE REAR DAMPERS
An adjuster wheel at the lower end of the unit allows continuous adjustment of the spring pre-load.
SPRING PRE-LOAD WHICH IS INCORRECT FOR THE RESPECTIVE WEIGHT OF THE
VEHICLE CAN IMPAIR THE QUALITY OF THE RIDE AND MAKE IT UNSAFE TO USE THE
TRIKE.
TO AVOID INJURY OR ACCIDENTS, WEAR PROTECTIVE GLOVES WHENEVER YOU
ADJUST THE DAMPERS.
ALWAYS ADJUST BOTH DAMPERS TO EXACTLY THE SAME SETTING.
C) Rear axle
The rear axle is equipped with alloy swinging arms on either side. Snail cam adjusters A+B allow you to
set toe-in and camber.
All V2-Trikes are set up correctly at the factory and will normally need no further adjustment.
The factory settings are:
Toe-in: - -
If tyre wear is uneven, then please contact a specialist dealer who can check camber and toe-in and if
required make the necessary adjustments.
Fig. 6
14
